Karl Andreevich Schilder (1786-1854)

Engineer-General Karl Andreevich Schilder is credited with having constructed the first submarine in Russia with an iron hull. Built at the Alexandrovsky Works plant in St. Petersburg and completed in May 1834. The boat had an egg-shaped form, two towers with access hatches and was equipped with an optical viewing tube, one of the first periscope devices for submersibles. An armament of mines and two triple-tube mountings for launching rocket projectiles was to be provided. To defeat an enemy vessel by using the mine it was necessary to stick a core of the mine in a hull, to move away to a safe distance and to blow up the mine by electric fuse.

Trails took place in September 1834 on the Neva River and the nearby island of Kronshtadt in the Gulf of Finland. The craft demonstrated an ability to submerge and was judged quite successful. An improvement version, equipped with diving plane to help control the craft underwater, was constructed in 1835, and with this second boat Schilder successfully destroyed a target ship with a mine in July 1838.

Trails with this boat were regularly conducted near Kronshtadtthrough 1841, but after some unexplained failure during trails in the fall of that year, Schilder was ordered to halt further experiments-as the boat was recognized unable for combat purposes. Lieutenants Zhmelev and Adamopulo were the first submarine commanders in Russia.

Specifications Schilder`s design (1834):

Displacement (srf/sub tons):
un known
Dimensions (L*B*D feet): 19`8*4`11*6`6
Propulsion: man-powered "vanes", akin to fish fins
Speed (srf/sub knots): un known /1.5
Range (srf/sub n/miles@knots): un known
Diving depth (feet): 40
Complement: 1 crew member
Torpedo: none
Mines: several
Armament: 2 triple-tube mountings for launching rocket projectiles

Back to History Index


Image Country Year Description
Russia 1993 K.A.Shilder (1786-1854) the first all metal submarine,1834
Saint Thomas 2009 Submarine designed by K.A.Shilder (1834), the first all metal submarine
